Triton Shipping AB

MV Eagle Fjord--reduced ideas-

PSV--DP 2
Classification Lloyd's Register ? 100 A1 Offshore Supply Vessel LMC UMS DP
(AA)

Built 1983 at Langstein, Norway

Gross Tonnage 2891 ton
Net Tonnage 867 ton
Deadweight at max draft 2976 ton

Length OA 88.1 meter
Length BP 80 meter
Breadth, Moulded 18.40 meter

Propulsion / Positioning
Main Engines 2 x WICHMANN 9AXAG, total output 5370 kW
Main Propellers 2 x CPP WICHMANN
Shaft Generators 2 x Siemens (capacity 2 x 1750 kW)
Auxiliary Generators 2 x Cummins (capacity 2 x 315 kW)
Bow Thruster 2 x 950 HP Brunvoll SPR-VP-950
Stern Thrusters 2 x 700 HP Brunvoll SPR-VP-750

Speed / Consumption
Economical speed 10.0 knots about 13 m3/day
Survey speed 4 knots about 10 m3/day
Full speed 14.0 knots about 16 m3/day
Maneuvering 3 knots about 5 m3/day
On DP (under average cond.) knots about 12 m3/day
In port about 2 m3/day

Cargo Capacities
Deck space 933 m2
Cargo deck capacity 2600 ton (max)
Deck length 61 m
Deck breadth 15.30 m lower part, 15.50 m upper part
Deck strength 5 t/m2
Fuel Oil 634 m3 in 10 tanks, 2 pumps, 2.1-250 m3/h 15 m/h pump capacity
Fresh Water 474.2 m3 in 7 tanks, 2 pumps, 130 m3/h pump capacity
Ballast Water 1150.5 m3
Liquid Mud 212.6 m3 (on request)
Dry Bulk 45 m3/tank, 6 tanks segregated system (on request)
Drill Water 1171 m3 in 8 tanks, 2 pumps, 160 m3/h pump capacity (on request)
Methanol 302 m3 (on request)
Slop 4.7 m3 in 1 tank, 2 m3/h pump capacity (on request)

Cargo Discharge Capacities
Fuel Oil 2 x 250 m3/hour at 15 bar with flow meter
Ballast / Drill Water 2 x 160 m3/hour at 7.3 bar
Fresh Water 2 x 130 m3/hour

Deck Equipment
Starboard Crane 1 x SWL 2.5 ton
Tugger/Capstan 2 x Norwinch 10 ton

Dynamic Positioning System
Class definition Dynapos-AUTR (IMO 2) K-Pos 21 (last FMEA June 2013)
DGPS DPS 100 / DPS 232

Accommodations:
Crew 31 crew in 9 single and 11 double cabins, all with bath room
Laundry 1
Hospital 1
Offices 1
Recreation 1
Lounges 1
Smoking Room 1

Navigation Equipment
Modern up to date!

Communication Equipment:
as per GMDSS A3, modern items.

We can guide accurate on price. Located N Cont area.

FROM DIRECT CLOSE FRIEND OWNERS, TO WHOM WE SOLD THIS SHIP AND FOR WHOM WE ACTED AS PANEL BROKERS LAST DECADE WE CAN DEVELOP SALE OF:

FLAG BELIZE

PORT OF REGISTRY BELIZE CITY
SERVICE SPEED 13.0 kn
STATUS OF SHIP IN SERVICE/COMMISSION
STATUS DATE (SINCE 28-10-2010)

GROSS TONNAGE 4386 t
NET TONNAGE 1316 t
DEADWEIGHT 4780 t
DISPLACEMENT 7353 t

LENGTH OVERALL 105.0 m
LENGTH REGISTERED 105.0 m
LENGTH BP 98.6 m
BREADTH EXTREME 18.03 m
BREADTH MOULDED 18.0 m
DEPTH MOULDED 7.0 m
DRAUGHT 5.013 m

FUEL TYPE MARINE DIESEL
PROPELLER 1 FIXED PITCH

BUILDER PRESIDENT MARINE PTE. LTD.
YARD NUMBER NB212
YEAR OF BUILT 1997

OWNERS ARE NOW SERIOUS SELLERS
WE CAN GUIDE ACCURATE

FROM CLOSE DIRECT EXCLUSIVE  OWNERS; TO WHOM WE SOLD THIS SHIP  AND FOR WHOM WE ACTED  LAST DECADE WE CAN DEVELOP FOR SALE:

CHEMICAL / OIL PRODUCTS TANKER

6400 DWT ON 7.17M DRAFT

IMO CLASS II, DOUBLE HULL (DOUBLE / DOUBLE)

BUILT: JUNE 1981, BY PAUL LINDENAU SHIPYARD, GERMANY

FLAG: RUSSIAN

CLASS: RMRS, ICE CLASS

CHEMICAL TANKER TYPE-2, OIL TANKER ESP ERS T1D21 T3D10

LAST / NEXT SPECIAL SURVEY: JUNE 2011/JUNE 2016 LOA / Lbp x B x D: 115.76 /

106.48 x 15.80 x 8.00 M GRT / NRT: 4270 / 1816 T CARGO TANKS: 12 + SLOP 2 EPOXY COATED & STAINLESS STEEL HEATING COILS CARGO CAPACITY: 6341M3 CARGO

PUMPS: 4 x 350M3/HOUR

4 SEGREGATIONS / SBT / CLOSED LDG / VAPOUR RETURN LINE

MAIN ENGINE: MAK 6M551AK, 2500 KW @ 450 RPM SPEED / CONSUMPTION: 13.5 KNOTS ON 10.8T IFO 380 CST BOWTHRUSTER FTTD CONTROLLABLE PITCH PROPELLER

OWNERS ARE NOW SERIOUS SELLERS

WE CAN GUIDE ACCURATE

Built in Finland 1964 at Valmet Shipyard, Pansio
Pleasure/Explorer/Expedition Yacht GT 164 NT 50 lengts 24,15m breath 7,00m Moulded depth 3,90 m
M/E Nohab diesel 303 kW fully overhauled into newlike condition. Hydraulic stabilisors new fitted. Bowthruster 60Hp installed new. Accomodation representativly rebuilt aiming at Luxury standards. Ready for delivery Cuxhaven

Price: best offers invited, we can fully guide.

Simplicity is the ultimate sophistication ! This is the NEW RIG Design by the famous Brian Chang. We are instructed by him personally to market this rig design and the first unit will be ready for work in Dec 2014. The Rig is a fantastic revolutionary design for especially shallow waters and marginal fields and a sister unit will be delivered every quarter thereafter. The Rig can withstand up to 90 ft waves! Can work on up to 500 feet WD and was approved under ABS Class. It has twice the deck space of a conventional 3 legged Cantilever JUR. The rig can as well easily be adjusted for Drilling, Accommodation or Production. We can offer it for sale or for BBC. Extremely cost effective due to low simple and fast mob/demob procedures. We can fully guide on prices for purchase or charter. We hold full and complete specs. The 1st Unit can be modified for an end users present needs and delivered ex China in Dec 2014.

Here we show just one of all the alternative working modes for the MCP :

 Blt Sietas, Germany 1990

 Finnish flag

 4.491 dwt

 1.032 lm

14 knots on 14 mt IF60/30, no MGO at sea

 4453 TDW RORO-SIDELOADER

GL 100 A5 E3 (ice 1A)

 Equipped for Carriage of Containers

  RORO-SIDELOADER

 Blt 1989, Sietas

 Dwt 4,453 tons

Speed abt 13 knots

 ME Wartsila 3,240 kW

 Loa 107.45 meter

 Beam 17.00 meter

 Deck heights

 Main deck 5,50 meter

 Lower hold 4,19 meter

 Hold volume - Deck area

 Main deck 6.687 m3 - 1.216 m2

 Lower hold 3.079 m3 - 735 m2

 Hatch dimensions (L x B)

 Hatch 1     25,50 x 14,50 m

 Hatch 2     12,60 x 10,10 m

 Hatch 3     25,50 x 14,50 m

 Cargo handling equipment

 Stern ramp 12,0 x 9,25 m (L x B)

Side loader with 2 lift platforms, 3,20 x 1,60 m each Lifting capacity 12 t per platform

 2 air drying aggregates for lower hold and main deck Container capacity and reefer plugs 180 TEU or 90 FEU on deck Stack load on deck 40-50 t per 20"-40" stack 20 reefer plugs on main deck and weather deck

Best offers invited

 SOLD

Classification                           DNV +1A1 SF E=

Supply ship. World Wide Trade
Class Status                             Special Survey done 2010-10. Annual done 2012-10

Design                                      UT 625

Built                                         Ulstein Hatlø AS, Norway

Delivered                                1976 yard no 137 Upgraded 1994-95, 2012

Flag                                         Norwegian (NIS)

Port of Registry                       Bergen, Norway

Owner                                     Eagle Shipping Ltd

Tonnage

Gross Tonnage                        1528    ton

Net Tonnage                            755    ton

Deadweight at max draft       3297    ton

Light Ship                                1838    ton

Dimensions

Length OA                               80.80   meter

Length BP                                76.20   meter

Breadth, Molded                     18.00   meter

Depth, Main deck                     7.10   meter

Draft Max                                4.30   meter

Propulsion / Positioning

Main Engines                          2 x 2,000         BHP, total 4,000 BHP MAK 6M53AK.
Propellers                                2 x C/P                        Hjelseth

Generators Shaft                     2 x 808            kW  Shaft generators

Generators                              2 x 360            kW Volvo

Generator Emergency            1 x 20              kW

Rudders                                   2 x                   Spade Split rudders of Ulstein Design

Thrusters                                 2 x 550            BHP Ulstein , total 1100 BHP, forward

                                                1 x 800            BHP Ulstein  aft

                                                1 x 500*          BHP, aft, Split Rudder giving side thrust

Joy Stick                                   Joy Stick          Scana Mar El system

Speed / Consumption

Cruising speed                            11.0 knots

Full speed                                  12.5   knots

   Cargo Capacities

Cargo Deck                              2500    ton (max)
Cargo Deck Max Load                    5   ton/m2

Cargo Deck Area Total              870    m2,
Cargo deck Length                      57     m
Cargo Deck Width                       15     m

Fuel Oil                                    1448    m3

Fresh Water                               562   m3

Brine                                         344    m3

Liquid Mud                                344    m3

Dry Bulk                                    268    m3 in 6 Cement tanks3

Ballast / Drill Water                 941    m3

Cargo Discharge Capacities

Fuel Oil                               1 x            250      m3/ hour at 6 bar. Flow Meter with print-out facility for fuel oil

Brine                                    2 x 75     m3/ hour at 16 bar

Ballast / Drill Water          2 x 125     m3 / hour at 6 bar
Fresh Water                       1 x 150     m3 / hour at 9 bar
1 x 75     m3 / hour at 6 bar

Mud                                       2 x 75    m3 / hour at 16 bar

Deck Equipment

Rails                                                    2.6 meters high

Capstan                                                           2 x Brattvaag 10 ton

Deck Crane                                          1 x NK25 25 t/m (SWL 2.2 ton)
Deck Crane                                          1 x Palfinger 8 t/m

Mooring Equipment

Windlass                                              1 x Brattvaag 10 ton anchor windlass

Anchors                                               2 x Anchors

Accommodations

Cabins                                                  8 Single bed cabins (Crew)

          3 Double bed cabins (Crew)
          4 x 2 bed cabin (Charter)
          22 beds total
1 Double bed Hospital

Anti Rolling System                             3 x Ulstein Anti rolling tanks

Satellit TV:                                           TV/DVD in all cabins, messroom and saloon/day room/bridge

Navigation Equipment

Radars                                      1 x Furuno FR2110 ARPA 3 cm

                                                1 x Sperry Bridgemaster ARPA 10 cm

Satellite Navigator                  1 x Furuno GP 80

                                                     1 x Furuno GP 70
Electronic chart display           1 x  Tel Charts ECS 2121 with C-map professional

Gyrocompass                           1 x Didgital Gyro STD 22 with repeaters

Sattelite Gyro Compass           1 x Electronic Overlands as coaxed with repeters

Navtex Receiver                      1 x MCmurdo ICS Nav 5 plus

Echo Sounder                           1 x Simrad EN

Autopilot                                  1 x Robertson AP 9 Mk 3

AIS                                               1 x Furuno FA 100
Wind indicator                                    1 x Simrad 1515

Communication Equipment
GMDSS                                    Area A3

MF/HF Radio                           1 x Sailor/Hasun RE 2100/2150 DCS
INMARSAT  C                           1 x Trane & Trane
VHF Radio telephone              2 x Sailor/Hasun RT 2147/2048

VHF/ DSC                                 2 x Sailor/Hasun 2042
VHF                                          2 x Sailor RT 2048

EPIRB                                       1 x TRON 40S

                                                1 x TRON 45 SX
VHF Emergency                      3 x Portable

Portable UHF                           6 x Portable 1 x Fixed

Portable VHF                              4 x Portable

Rescue Equipment

Fast Rescue Craft                    1 x Alusafe 20 FRC with outboard

Fast Rescue Craft Davits         1 x Solas Davit

Life rafts                                  4 x 20 person
All Lifesaving for                     22 person  and according to DNV class and SOLAS requirement
